optical flow - python, opencv, 추상화 클래스 추가 구현

from abc import ABC, abstractmethod # type: ignore

import cv2

import numpy as np

# ---------------------------

# 추상 클래스: 객체 검출

# ---------------------------

class ObjectDetector(ABC):

    @abstractmethod

    def detect_objects(self, frame):

        pass

# ---------------------------

# YOLO 기반 객체 검출 구현

# ---------------------------

class YOLOProcessor(ObjectDetector):

    def __init__(self, config_path, weights_path, classes_path, score_threshold=0.5, nms_threshold=0.4):

        self.net, self.classes = self._initialize_yolo(config_path, weights_path, classes_path)

        self.score_threshold = score_threshold

        self.nms_threshold = nms_threshold

    def _initialize_yolo(self, config_path, weights_path, classes_path):

        with open(classes_path, 'r') as f:

            classes = [line.strip() for line in f.readlines()]

        net = cv2.dnn.readNet(weights_path, config_path)

        net.setPreferableBackend(cv2.dnn.DNN_BACKEND_OPENCV)

        net.setPreferableTarget(cv2.dnn.DNN_TARGET_CPU)

        return net, classes

    def detect_objects(self, frame):

        blob = cv2.dnn.blobFromImage(frame, 1 / 255.0, (416, 416), swapRB=True, crop=False)

        self.net.setInput(blob)

        layer_outputs = self.net.forward(self.net.getUnconnectedOutLayersNames())

        boxes, confidences = [], []

        for output in layer_outputs:

            for detection in output:

                scores = detection[5:]

                class_id = np.argmax(scores)

                confidence = scores[class_id]

                if self.classes[class_id] == "person" and confidence > self.score_threshold:

                    center_x = int(detection[0] * frame.shape[1])

                    center_y = int(detection[1] * frame.shape[0])

                    w = int(detection[2] * frame.shape[1])

                    h = int(detection[3] * frame.shape[0])

                    x = int(center_x - w / 2)

                    y = int(center_y - h / 2)

                    boxes.append([x, y, w, h])

                    confidences.append(float(confidence))

        indices = cv2.dnn.NMSBoxes(boxes, confidences, self.score_threshold, self.nms_threshold)

        # 수정된 부분: indices 처리

        final_boxes = []

        if indices is not None:

            if isinstance(indices, (list, np.ndarray)):  # 리스트나 배열인 경우

                final_boxes = [boxes[i] for i in indices.flatten()]  # indices를 평탄화 후 순회

            elif isinstance(indices, int):  # 스칼라인 경우

                final_boxes = [boxes[indices]]

        return final_boxes

# ---------------------------

# 추상 클래스: 옵티컬 플로우

# ---------------------------

class FlowProcessor(ABC):

    @abstractmethod

    def calculate_flow(self, prev_gray, gray, box):

        pass

# ---------------------------

# 옵티컬 플로우 계산 구현

# ---------------------------

class OpticalFlowProcessor(FlowProcessor):

    def __init__(self, frame_rate):

        self.frame_rate = frame_rate

    def calculate_flow(self, prev_gray, gray, box):

        x, y, w, h = box

        roi_prev_gray = prev_gray[y:y+h, x:x+w]

        roi_gray = gray[y:y+h, x:x+w]

        if roi_prev_gray.size == 0 or roi_gray.size == 0:

            return None, None, None

        flow = cv2.calcOpticalFlowFarneback(roi_prev_gray, roi_gray, None, 0.5, 3, 15, 3, 5, 1.2, 0)

        valid_magnitude = np.sqrt(flow[..., 0]**2 + flow[..., 1]**2)

        threshold = np.percentile(valid_magnitude, 80)

        valid_mask = valid_magnitude > threshold

        avg_fx = np.mean(flow[..., 0][valid_mask])

        avg_fy = np.mean(flow[..., 1][valid_mask])

        avg_speed = np.mean(valid_magnitude[valid_mask]) * self.frame_rate if valid_mask.any() else 0

        return avg_fx, avg_fy, avg_speed

# ---------------------------

# 비즈니스 로직: 동영상 처리

# ---------------------------

class VideoProcessor:

    def __init__(self, video_path, detector: ObjectDetector, flow_processor: FlowProcessor, frame_width=640, frame_height=360):

        self.video_path = video_path

        self.detector = detector

        self.flow_processor = flow_processor

        self.frame_width = frame_width

        self.frame_height = frame_height

        self.direction_buffer = {}

    def process(self):

        cap = cv2.VideoCapture(self.video_path)

        ret, prev_frame = cap.read()

        if not ret:

            print("동영상을 열 수 없습니다.")

            cap.release()

            return

        prev_frame = cv2.resize(prev_frame, (self.frame_width, self.frame_height))

        prev_gray = cv2.cvtColor(prev_frame, cv2.COLOR_BGR2GRAY)

        frame_rate = cap.get(cv2.CAP_PROP_FPS)

        while True:

            ret, frame = cap.read()

            if not ret:

                cap.set(cv2.CAP_PROP_POS_FRAMES, 0)

                continue

            frame = cv2.resize(frame, (self.frame_width, self.frame_height))

            gray = cv2.cvtColor(frame, cv2.COLOR_BGR2GRAY)

            final_boxes = self.detector.detect_objects(frame)

            for i, box in enumerate(final_boxes):

                avg_fx, avg_fy, avg_speed = self.flow_processor.calculate_flow(prev_gray, gray, box)

                if avg_fx is None or avg_fy is None:

                    continue

                if avg_fx > 0:

                    avg_fx = -np.abs(avg_fx)

                if np.abs(avg_fy) > 0.2:

                    avg_fy = 0

                if i not in self.direction_buffer:

                    self.direction_buffer[i] = (avg_fx, avg_fy)

                else:

                    prev_fx, prev_fy = self.direction_buffer[i]

                    avg_fx = 0.8 * prev_fx + 0.2 * avg_fx

                    avg_fy = 0.8 * prev_fy + 0.2 * avg_fy

                    self.direction_buffer[i] = (avg_fx, avg_fy)

                self._draw_arrow_and_text(frame, box, avg_fx, avg_fy, avg_speed)

            cv2.imshow('YOLO + NMS + Optical Flow', frame)

            prev_gray = gray

            if cv2.waitKey(1) & 0xFF == ord('q'):

                break

        cap.release()

        cv2.destroyAllWindows()

    def _draw_arrow_and_text(self, frame, box, avg_fx, avg_fy, avg_speed, arrow_width=3, x_scale_factor=0.25):

        """

        Draws an arrow indicating the movement direction and a text showing the speed.

        :param frame: The frame to draw on.

        :param box: The bounding box coordinates (x, y, w, h).

        :param avg_fx: Average flow in the x-direction.

        :param avg_fy: Average flow in the y-direction.

        :param avg_speed: The calculated speed of the object.

        :param arrow_width: The width of the arrow (default: 5).

        :param x_scale_factor: Scaling factor for the arrow's x-axis length (default: 0.5).

        """

        x, y, w, h = box

        text = f"Speed: {avg_speed:.2f} px/s"

        text_size = cv2.getTextSize(text, cv2.FONT_HERSHEY_SIMPLEX, 0.6, 2)[0]

        vector_length = text_size[0]  # Base length for the arrow

        # Normalize the direction vector

        magnitude = np.sqrt(avg_fx**2 + avg_fy**2) + 1e-6

        direction_x = (avg_fx / magnitude) * vector_length * x_scale_factor  # Apply x-axis scale

        direction_y = (avg_fy / magnitude) * vector_length  # Keep y-axis length unchanged

        # Calculate arrow start and end points

        arrow_start = (x + w // 2, y - 10)  # Arrow starts slightly above the box

        arrow_end = (x + w // 2 + int(direction_x), arrow_start[1] - int(direction_y))

        text_position = (arrow_start[0] - text_size[0] // 2, arrow_start[1] - 15)

        # Draw arrow

        cv2.arrowedLine(frame, arrow_start, arrow_end, (0, 0, 255), arrow_width, tipLength=0.2)

        # Draw text

        cv2.putText(frame, text, text_position, cv2.FONT_HERSHEY_SIMPLEX, 0.6, (255, 255, 255), 2)

        # Draw bounding box

        cv2.rectangle(frame, (x, y), (x + w, y + h), (0, 255, 0), 2)

# ---------------------------

# 실행 코드

# ---------------------------

if __name__ == "__main__":

    yolo_config = 'D:\\yolov4-tiny.cfg'

    yolo_weights = 'D:\\yolov4-tiny.weights'

    yolo_classes = 'D:\\coco.names'

    video_path = 'D:\\video.mp4'

    yolo_processor = YOLOProcessor(yolo_config, yolo_weights, yolo_classes)

    flow_processor = OpticalFlowProcessor(frame_rate=30)

    video_processor = VideoProcessor(video_path, yolo_processor, flow_processor)

    video_processor.process()
